Introduction

Create this one eyed monster and make his eye spin!

This can be created with our Paper Circuits Kit and a barrel motor!

Video Overview

Featured Document

  1. Make sure to print this template single-sided. You will be making a project with two distinct layers with a small gap in between.
    • Make sure to print this template single-sided. You will be making a project with two distinct layers with a small gap in between.

  2. Color and cut out the top layer of the monster template, the eye, and the switch. Cut out the small circle in the middle of the monster. We will be putting the motor through this hole in a later step.
    • Color and cut out the top layer of the monster template, the eye, and the switch.

    • Cut out the small circle in the middle of the monster.

    • We will be putting the motor through this hole in a later step.

    • You do not need to cut out the template that has the circuitry. This space on the paper around the monster can be decorated to depict a scene.

  3. Add a piece of double-sided foam tape to the center of the bottom layer. Stick the motor to the double sided tape making sure the back of the motor (with the wires) is stuck down to the tape and the part that spins faces upwards so it can move freely. Stick the motor to the double sided tape making sure the back of the motor (with the wires) is stuck down to the tape and the part that spins faces upwards so it can move freely.
    • Add a piece of double-sided foam tape to the center of the bottom layer.

    • Stick the motor to the double sided tape making sure the back of the motor (with the wires) is stuck down to the tape and the part that spins faces upwards so it can move freely.

  4. Add Tape Path A. pressing it down atop the blue wire. If your wires are reversed it will just change the direction the motor rotates.
    • Add Tape Path A. pressing it down atop the blue wire.

    • If your wires are reversed it will just change the direction the motor rotates.

  5. Make a loop of tape (sticky side out) using a short piece of Maker Tape, and stick it atop the end of Path A. Make a loop of tape (sticky side out) using a short piece of Maker Tape, and stick it atop the end of Path A.
    • Make a loop of tape (sticky side out) using a short piece of Maker Tape, and stick it atop the end of Path A.

  6. Once your tape loop is in place you can add the Battery to it.
    • Once your tape loop is in place you can add the Battery to it.

    • Make sure the Positive side of the Battery is facing upwards, with the Negative side stuck down to the tape.

  7. Add tape Path C. to the top of the battery and onto the template.
    • Add tape Path C. to the top of the battery and onto the template.

  8. Add tape Path D.
    • Add tape Path D.

  9. Add tape Path E. pressing it down atop the red wire. Add tape Path E. pressing it down atop the red wire.
    • Add tape Path E. pressing it down atop the red wire.

  10. If you haven't made a paper lever switch yet see the guide: Switch - Lever Switch Add the paper switch to the end of Path E. so that the Maker Tape overlaps.
    • If you haven't made a paper lever switch yet see the guide: Switch - Lever Switch

    • Add the paper switch to the end of Path E. so that the Maker Tape overlaps.

    • Make sure the other end of the paper switch comes in contact with Path D.

    • If the switch does not reach the Path D. tape you can adjust and add more Maker Tape as needed.

    • At this point you should test the circuit to make sure it works. When you press down on the switch the motor should spin.

    • It is easier to fix the circuit if it is not working before adding the top monster layer.

    • If it does not spin...

    • Make sure that your switch is making contact.

    • Make sure your motor can spin freely and doesn't have tape or glue impeding movement.

  11. Add four small pieces of double-sided foam tape to the squares around the outline of the monster. Place the cut out monster template over the top of the motor so the motor goes through the small hole you cut earlier. Press down on top of the template to adhere the top layer to the foam tape.
    • Add four small pieces of double-sided foam tape to the squares around the outline of the monster.

    • Place the cut out monster template over the top of the motor so the motor goes through the small hole you cut earlier.

    • Press down on top of the template to adhere the top layer to the foam tape.

  12. Add another square of double-sided tape onto the shaft of the motor, and then stick the eye to it. Add another square of double-sided tape onto the shaft of the motor, and then stick the eye to it. Add another square of double-sided tape onto the shaft of the motor, and then stick the eye to it.
    • Add another square of double-sided tape onto the shaft of the motor, and then stick the eye to it.

    • The switch is underneath the swirl pattern on the monster. Tap the swirl to make your monster's eye spin!
